2023 New JH-6A Electrical VTOL Fixed-Wing UAV


Keywords :

UAV / drone / aircraft


  • Hits : 420
  • Company : Dongguan Jinhong Aviation Technology Co., Ltd.
  • Telephone : +86-18664149308
Contact Us

Product Details

Contact Us

Five Advantages Of Products

  • VTOL/Fixedwing carbon fiber propellers
  • Advanced aerodynamic design
  • Dual GPS differential design
  • ESC Telemetry, increasing flight stability and safety
  • Redundant airspeed measurement system

Product Details

We are a professional industrial UAV solutions provider with more than 12 years of experience!

Our Main Solutions
1. Mapping, surveying and 3D modeling

2. Surveillance
3. Inspection
4. Delivery
5. Customization according to application and client's requirements

Below is the details of our JH-6A:

Flight platform: composite wing flight platform

Body material: carbon brazing, FRP composite material

Takeoff weight: ≥6.9kg

Endurance: 180min

Battery capacity: 3000mah 6S

Task radius: ≤30km

Hover accuracy: horizontal ±0.15m, vertical ±0.1m

Cruising speed: ≥17m/s

Wind resistance grade: 7 wind (12m/s)

Maximum range: 180km

Body length: 1190mm

Body width: 2500mm

Fuselage height: 380mm

Maximum range: 180km

Altitude: 6800m

Onboard camera: Sony Rx1r, Sony A7R, 102S, DG3, multi-spectral camera, visible light tracking, dual light tracking, thermal imager and other 2kg cameras

Adapt to weather: light rain, light snow

Ambient temperature: -10 ° C to +65 ° C






JH-6A (2).jpg
